Sany Heavy Industry's STC1600 crane has the advantages of high lifting capacity, strong flexibility, simple operation, safety and reliability, energy saving and environmental protection, strong fault detection ability and strong adaptability, and is widely used in various engineering fields.
| SANY STC1600 | |
| Maximum rated lifting capacity (t) | 160 |
| Maximum rated lifting torque (KN.m) | 5240 |
| Maximum lifting height - fully extended arm (m) | 115 |
| Maximum lifting capacity (tons) | 91-180 tons |
| Full extension time of lifting arm (s) | 800 |
| Slewing speed (rpm) | 1.5 |
| Rated power (kw/rpm) | 176/2300 |
| Maximum driving speed (km/h) | 80 |
| Minimum turning radius (m) | 8.5 |
| Maximum climbing grade (%) | 46 |
| Approach angle/departure angle (°) | 19/15 |
| Overall length of the whole machine (mm) | 16225 |
| Overall width of the whole machine (mm) | 2800 |
| Overall height of the whole machine (mm) | 4000 |
| Operating weight (t) | 54.99 |
| Total counterweight (t) | 56.5 |
