Used SANY 220 TON Crane Truck

WhatsApp Inquiry Now

The STC2200 crane has the advantages of high load-bearing capacity, high efficiency, flexibility, safety, easy operation and maintenance. It is a high-performance crane model.

Specifications

SANY STC2200
Maximum rated lifting capacity (t)	220
Maximum rated lifting torque (KN.m)	7408
Maximum lifting height - fully extended arm (m)	68.5
Maximum lifting capacity (tons)	181-300 tons
Full extension time of lifting arm (s)	600
Slewing speed (rpm)	1.5
Rated power (kw/rpm)	358/2800
Maximum driving speed (km/h)	80
Minimum turning radius (m)	8.5
Maximum climbing grade (%)	46
Approach angle/departure angle (°)	18/14
Overall length of the whole machine (mm)	16476
Overall width of the whole machine (mm)	3000
Overall height of the whole machine (mm)	4000
Operating weight (t)	54.98
Total counterweight (t)	56.5
